Ashdown ABM-300-EVO IV Bass Amp Head

Here’s what Ashdown says about the ABM-300-EVO IV:

Immediately identifiable on stages around the world thanks to it’s glowing VU meter. Over the past 20 years the Ashdown ABM range has become the industry standard for bass players in pursuit of real bass tone, power, versatility and tour proven reliability.

Now in its fifth incarnation, ABM EVO IV pairs class-leading preamp sophistication with uprated powerhouse performance and an all-new 9-band EQ – available in three head versions rated at 300W, 600W and 1200W. The ABM 300 EVO IV teams the ABM preamp with a powerful 300W power stage perfect for clubs and mid sized venues.

Variable Valve Drive Plus – From Zero To Rock Hero!

Our Variable Valve Drive preamp section has also been upgraded in EVO IV. Delivering more current to the 12AX7 tube enables more drive and harmonic content than ever before, enabling players to dial in a sound from pristine clean, to the fattest, fullest bass overdrive currently available. The Drive level can be preset and kicked in and out via footswitch, providing access to a huge range of clean, warm and overdriven tones.

The Best EQ In The Business, Just Got Better!

Bassists plugging into EVO IV will be greeted straight away by the flickering of the new Input VU meter, allowing them to quickly find the sweet spot for their instrument. From there, EVO IV features a sophisticated 9-band EQ, with familiar Bass, Middle and Treble controls and six sliders providing precision cut and boost at 100Hz, 180Hz, 340Hz, 1.3KHz, 2.6KHz and 5KHz. The EQ can be switched in via footswitch taking the player from a flat fretless sound to their favourite EQ setting instantly. The NEW 9-band EQ is a revelation of sonic perfection and will surprise older ABM users.

One Knob Compressor

Other ABM favourite features are retained in EVO IV, including Ashdown’s famous One Knob Dynamic Compressor sub octave note for huge bass tones. Kick it in and this simple to use, great sounding compressor delivers a powerful, even sound, guaranteed to help your bass fill out any mix.

Sub-Harmonic Generator

Once heard – never forgotten. The ABM Sub-Harmonic generator adds an octave below the notes being played bringing fullness to any bass part. The Sub level is independently controllable, letting you dial in anything from a subtle hint of deep bass to a full-on subterranean funk.

Professional Connections

Not that you’d expect any less, ABM is loaded with connectivity. A tuner output, Line out, transparent FX loop and a Line Input for the connection of an external sampler or sound source. Output muting cuts the signal from the DI output but leaves the tuner output ‘live’, allowing the player to tune up in silence.

A pair of Neutrik Jack/Speakon sockets with a minimum 4 ohm load provide flexible partnering options with a dedicated range of ABM EVO IV cabinets. The ABM 300 EVO IV can be used to power a single 8 ohm cabinet, a pair of 8 ohm cabinets or a single 4 ohm cabinet.

Specifications

• Power Output: 300 Watts
• Power Requirement: 115-230 Volts
• Speaker Outputs: 2 x Neutrik Jack/Speakon outputs
• Frequency Response: -3dB @ 17Hz und 30KHz
• High Instrument Input: Impedance 3.9m Ohms, input range 150mV
• Low Instrument Input: Impedance 10k Ohms, input range 300mV – 40V p-p
• Line Input: Impedance 22k Ohms, input level 0dBu nominal
• DI Output: 600 Ohm balanced, Level 0dBu nominal
• Tuner Output: Impedance 22k Ohms, Level 0dBu nominal
• Impedance: Minimum 4 Ohms
• Effects Send: Impedance 22k Ohm, Level 0dBu nominal
• Effects Return: Impedance 22k Ohms, Input Level 0dBu Nominal
• Pre Amp Tubes: 1 x 12AX7
• H x W x D (mm): 135 x 474 x 335
• Weight (kg): 12
